3,4 and 5 Way for Pneumatic and Hydraulic use

Web design encompasses many different skills and disciplines in the production and maintenance of websites. The different areas of web design include web graphic design; interface design; authoring, including standardised code and proprietary software; user experience design; and search engine optimization. Often many individuals will work in teams covering different aspects of the design process, although some designers will cover them all.[1] The term web design is normally used to describe the design process relating to the front-end (client side) design of a website including writing mark up. Web design partially overlaps web engineering in the broader scope of web development. Web designers are expected to have an awareness of usability and if their role involves creating mark up then they are also expected to be up to date with web accessibility guidelines.

Compact valve convertible from 5/2 to 3/2 NC.NAMUR mount construction.Pilot operated. BSP or NPT input and exhaust threaded connections.Buna “N” seals. Forged brass compact body.Core tube: 304 s.s. Core spring: 302 s.s. Core: 430F s.s.Shading co

THB 0 ฿ 0

For compressed air and other neutral gases.Forged brass body. Buna “N” seals and seats.BSP or NPT 1/4” threaded connections.Servo operated action. Shape A DIN 43650 connection encapsulated coil. IP65 NEMA 4 protection.Core tube: 304 s.s. Core spri

THB 0 ฿ 0

4 ways, 3 positions, closed center. It allows to operate double acting cylinders or actuators. Aluminium, brass and stainless steel body. BSP or NPT 1/4", 3/8", 1/2" threaded connections. Seat shutoff, 4 diaphragms which plug up therespective ways. High capacity and operation speed. No need for lubrication to operate, ideal for instrument air. Pilot orifices with internal discharge, it may operate dangerous fluids or those which do not allow spills, such as gas, fuel, water, light oils and other similar fluids. Shape A DIN 43650 connection encapsulated coils. IP65 and NEMA 4 protection. Core tube: 304 s.s. Core spring: 302 s.s. Core: 430 F s.s. Shading coil: copper (brass or aluminium body) silver (s.s. body).

THB 0 ฿ 0

3 ways, 2 positions.Normally closed.Direct acting or pilot operated.Brass body.Buna N seals.NAMUR Mount.Shape A DIN 43650 connection encapsulated coils.IP65 and NEMA 4 protection.Core tube: 304 s.s. Core spring: 302 s.s. Core: 430 F s.s.

THB 0 ฿ 0

5 ways, 2 positions, monostable.Pilot operated.Forged brass body.Buna “N” seals.NAMUR mount.Shape A DIN 43650 connection encapsulated coils.IP65 and NEMA 4 protection.Core tube: 304 s.s. Core spring: 302 s.s. Core: 430 F s.s.Shading coil:

THB 0 ฿ 0

3 Ways, 2 positions, normally closed, normally open or universal.Direct acting. No minimum differential pressure to operate.Body: brass, iron, stainless steel, etc.BSP or NPT 1/4" Connection.Buna N seats for neutral fluids up to 80ºC.Seats: neop

THB 0 ฿ 0

3 ways, 2 positions, normally open or normally closed.Aluminium, brass, stainless steel body.BSP or NPT threaded connections.Buna “N” seals for neutral fluids up to 80ºC.FKM seals for other uses.PTFE sleeve for instrument air and dry gases.Sha

THB 0 ฿ 0

5 ways, 2 positions, monostable or bistable.Aluminium, brass, stainless steel body.BSP or NPT threaded connections.Buna “N” seals for neutral fluids up to 80º C.FKM seals for other uses.PTFE sleeve for instrument air and dry gases.Shape A DIN

THB 0 ฿ 0

3 ways, 2 positions, normally closed, normally open.Pilot operated.Seat shutoff. No need for lubrication to operate.Body: brass, stainless steel, etc.BSP or NPT threaded connections.Buna N diaphragm and seats for neutral fluids up to 80ºC.FKM diaphragm and seats for other uses.Shape A DIN 43650 connection encapsulated coils.IP65 and NEMA 4 protection. Pilot orifice with internal discharge. It may be used with fluids which cannot be discharged into the atmosphere.Greater flow capacity and lower response time than any other spool valve of the same size.Core tube: 304 s.s. Core spring: 302 s.s. Core: 430 F s.s.Shading coil: copper (brass body) silver (s.s. body).

THB 0 ฿ 0

3 Ways, 2 positions, normally closed, normally open or universal.Direct acting. No minimum differential pressure to operate. Body: brass, iron, stainless steel, etc.BSP or NPT 1/4" Connection.Buna N seats for neutral fluids up to 80ºC.Seats: neo

THB 0 ฿ 0
